Product Features« Ultra-thin design, lightweight
« Novel structure, beautiful appearance
« Multiple seals, waterproof, dustproof, vibration-resistant, low power consumption, long lifespan
« Its core circuit is controlled by a single-chip microcomputer. The software "watchdog" and hardware anti-interference measures ensure the reliability of the countdown timer operation
« It has multiple installation methods, suitable for different installation environments, and the construction and installation are extremely convenient
« No need to connect an additional power supply. Just connect the wires from the traffic signal light
« Assembled using modularization methods, the repair and replacement of components are extremely quick
« Unique optical system, wide viewing angle, uniform color, long visible distance, the display part uses ultra-high-brightness light-emitting diodes, stable performance, and ideal display effect
« Has the function of overcoming 5-second yellow flash. When the signal is in a 3-5-second transition yellow flash, the countdown will be normal and will not be incorrect
« During night yellow flash or emergency yellow flash, the countdown automatically detects and closes the output
« Multiple inputs, each direction only requires 1 group of countdown, which can count the green lights of the left turn, straight, and right turn lanes, as well as the red and yellow lights of the main lane
« The internal power supply uses a new type of switching power supply (the traditional one uses a transformer), wide voltage design (voltage range AC85-265V), lightning protection and performance are more stable.
« The control board of the countdown timer adopts a dual lightning protection circuit, enabling the product to work stably in harsh weather conditions.
Complies with GAT508-2004 and international relevant standards
Technical Parameters Red countdown: 546 LEDs, individual brightness: 2500 - 4000, wavelength: 630 ± 5 nm, viewing angles (left-right, up-down): 30°, power: ≤ 20W.
Green countdown: 336 LEDs, brightness of each LED: 4000 - 5600, wavelength: 505 ± 5 nm, viewing angles (left-right, up-down): 30°, power: ≤ 20W.
Environmental temperature: -40℃ to +80℃
Operating voltage: AC 185V - 265V 60Hz/50Hz
Exterior material of the light box: Cold-rolled sheet or aluminum
Light assembly size (mm): 800 x 600 x 10
Five-lamp horizontal wiring diagram
Three-lamp horizontal wiring diagram
Three-lamp Vertical installation wiring diagram
(Allow left turn first, then allow straight ahead.)
Three-lamp Vertical installation wiring diagram
(Allow left turn first, then allow straight ahead.)
Intersection effect drawing
Customization supported as per your demands & drawings. Contact us for details.
